Nauta Mixer-Cone Screw Mixer

Name: Nauta Mixer-Cone Screw Mixer
Brand: THE BOMBAY ENGINEERING WORKS
Price: 250000 INR
Availability: InStock

Price 250000 INR/ Unit

Get a Price/Quote

Nauta Mixer-Cone Screw Mixer Specification

Usage & Applications
Mixing powders, granules, pastes in chemical, pharmaceutical, food, cosmetic, and allied industries

Frequency
50 Hz / 60 Hz

Phase
Three Phase

Noise Level
Low

Temperature
Ambient, can be customized up to 200C

Features
Efficient mixing, gentle blending, minimum heat generation, easy cleaning and discharge, dustproof design

Type
Nauta Mixer (Cone Screw Mixer)

Material
Stainless Steel (SS304 / SS316), Mild Steel (optional)

Capacity
50 L to 10,000 L

Computerized
No

Control Mode
Automatic / Semi-Automatic

Voltage
220V / 380V / 415V

Power
2 kW - 30 kW (depending on model)

Weight (kg)
Varies as per model and capacity

Dimension (L*W*H)
Custom, based on capacity

Color
Silver (Stainless Steel Finish)

Sealing
Dust proof rotary shaft seals

Maintenance
Low, easy access for cleaning and servicing

Heating/Cooling Option
Optional jacketed vessel for temperature control

Safety Features
Overload protection, emergency stop switch

Mixer Speed
Screw: 18-25 rpm; Arm: 1-3 rpm (approximate)

Mixing Precision
Up to 1:100,000 coefficient of variation (CV)

Discharge Valve
Butterfly valve or slide gate as per application

Drive System
Top mounted, geared motor drive

Surface Finish
Mirror / matte polish for product contact parts

Design Standard
cGMP and ASME compliant

Scale-up
Design available for laboratory, pilot scale, and production-scale batches

About Nauta Mixer-Cone Screw Mixer

Product details

Model Number	CM-0.1
Motor Power	1.5 Kw
Nominal Volume	100L
Working Volume	40-60L
Warranty	1 YEAR
Material	Stainless Steel
Phase	3 pHASE
Speed	3rpm (orbit),118rpm (screw)
Model Name/Number	"BOMBAYENGG"
Capacity	25 kgs to 5000 kgs / batch

Superior Mixing Precision for Diverse Applications

Achieve thorough and gentle blending of powders, granules, and pastes with the Nauta Mixer-Cone Screw Mixer. Its advanced screw and arm movements create a homogenous mixture, ideal for industries with high quality standards. The system is adaptable across laboratory, pilot, and production scales, making it a reliable solution for various operational needs.

User-Oriented Design with Robust Safety Features

Built with user safety in mind, the mixer comes with overload protection and an emergency stop switch. All product contact surfaces are finished in mirror or matte polish to ensure hygiene and easy cleaning. The design supports rapid access for maintenance, minimizing downtime and streamlining servicing tasks.

FAQs of Nauta Mixer-Cone Screw Mixer:

Q: How does the Nauta Mixer ensure such precise mixing results?

A: The Nauta Mixer employs a conical screw mechanism with simultaneous rotation and revolution, effectively blending materials and achieving up to 1:100,000 coefficient of variation (CV). This ensures even distribution of components throughout the batch, resulting in optimal product uniformity.

Q: What industries benefit most from using this mixer?

A: Industries such as pharmaceuticals, chemicals, food processing, cosmetics, and allied sectors greatly benefit due to the mixers gentle yet efficient handling of powders, granules, and pastes, along with its dustproof design and compliance with leading quality standards.

Q: When should I choose the optional heating or cooling jacket?

A: Opt for the jacketed vessel when your process requires precise thermal controlsuch as sensitive formulations needing consistent heating or cooling up to 200C during mixing. This feature helps maintain product quality and optimizes processing conditions.

Q: Where can the Nauta Mixer be installed and what utilities does it require?

A: The mixer is suitable for installation in industrial facilities worldwide. It is available in three-phase configurations (220V/380V/415V, 50Hz/60Hz) and needs only standard power supply, without any requirement for computerization. Dimensions and weight are customized per capacity, allowing seamless integration.

Q: What makes the cleaning and maintenance process straightforward?

A: The design offers easy access to internal components, minimizing disassembly for routine cleaning and servicing. The mirror/matte polish on product contact parts resists residue buildup, supporting fast and sanitary maintenance with minimal effort.

Q: How does the discharge system suit different applications?

A: Depending on your process flow and product characteristics, you can choose between a butterfly valve or slide gate discharge valve. Both options facilitate efficient product release while maintaining the systems dustproof integrity and hygiene.
